尺寸標示：H x W x D mm
| 外框 Frame |
木框、鍍鋅鐵框、鋁框、不鏽鋼框 Wooden, Galvanized Steel, Aluminum or Stainless Steel |
|
| 濾材 Media |
玻璃纖維紙 Waterproot fire retardant glassfiber |
|
| 墊片 Gasket |
Neoprene EPDM |
|
| 接著材 Bond |
環氧樹脂 Epoxy Resin PU Fire-retardant Urthane |
|
| 最高溫度 Temperature |
80°C | |
| 最高濕度 Humidity % RH |
100% (無結霧狀態下) 100% (No condensation state) |
|
| 測試方法 Test Method |
大氣塵 SCANNING TEST BY ATMOSPHERIC DUST
DOP PAO 光度計掃描測試 (SCANNING TEST BY PAO) |
|
| 補集效率 ASHRAE Efficiency ASHRAE |
65%~95% | |
| 補集效率 HEPA Efficiency HEPA |
≥99.97% . ≥99.99% (0.3μm) | |
| 補集效率 ULPA Efficiency ULPA |
≥99.999% . ≥99.9995% . ≥99.9999% (0.1μm-0.2μm) | |
| 效率 Efficiency (%) |
通稱尺寸 Nominal Size (W x H x D) inch |
實際尺寸 Actual Size (W x H x D) mm |
額定風量 Rated Capacity (CMH) |
初期壓損 INITIAL P.D (pa) |
最終壓損 FINAL P.D (pa) |
| 標準風量 Standard Capacity |
|||||
| 95 | 12x24x6 | 305x610x150 | 850 | 150 | 374 |
| 24x24x6 | 610x610x150 | 1700 | |||
| 12x24x12 | 305x610x292 | 1700 | 237 | 500 | |
| 24x24x12 | 610x610x292 | 3400 | |||
| 99.97 99.99 |
12x24x6 | 305x610x150 | 600 | 250 | 500 |
| 24x24x6 | 610x610x150 | 1200 | |||
| 12x24x12 | 305x610x292 | 950 | |||
| 24x24x12 | 610x610x292 | 1900 | |||
| 高風量 High Capacity |
|||||
| 99.97 99.99 |
12x24x12 | 305x610x292 | 1700 | 336 | 500 |
| 12x24x12 | 610x610x292 | 3400 | |||
※ 特殊尺寸或規格可依客戶需求製作。
※ Special dimension can be customized.
